- High performance programmable digital standard servo, can be common use in robots, mechanical arms, climbing cars and remote control toys.
- The main features are fast heat dissipation, high torque high compatibility, sensitive and responsive ect.
- Torque: 21 kg/cm at(5V), 24.5 kg/cm.at (6.8V)
- Operating Voltage: 4.8 ~ 6.8 DC Volts
- Working frequence: 1520μs / 333hz
Features:
- High-precision metal gears with hard anodizing
- CNC aluminium middle shell
- Dual ball bearings
- Less Noise
Parameter:
Torque: 21 kg/cm at(5V), 24.5 kg/cm.at (6.8V);
Motor Type: DC Motor;
Speed : 0.15 sec/60°(5V) / 0.13 sec/60°(6.8V);
Weight: 60 g (2.12 oz) ;
Operating Voltage: 4.8 ~ 6.8 DC Volts;
Dead brand: 3μs
Size: 40 x 20 x 40.5 mm ( 1.58 x 0.79 x 1.60 in) ;
Gear Type: Copper & Aluminum;
Working frequence: 1520μs / 333hz;
